Commercial CCTV
Office CCTV Installation in Lahore
Zone-wise coverage for reception, corridors, work floor, server room and cash handling — installed with structured cabling, documented scope and a proper invoice for your records.
Coverage Planned Around How the Workplace Runs
A workplace system has a different job to a home system. It is rarely about a break-in. It is about knowing who was in the building after hours, who went into the server room, who signed for a delivery, and what actually happened when two accounts of the same incident do not agree.
A large share of Lahore workplaces sit in converted houses along commercialised roads in Gulberg, Johar Town and Model Town, where the layout you survey today is not the layout you will have after partitioning. We design for the final floor plan wherever the client has one, because moving a camera after the false ceiling goes in costs more than fitting it in the right place first.
All hardware is Contact for Price. Send a floor plan or a few photos to WhatsApp on WhatsApp, or email info@strixlink.com, and we will return a written scope you can put in front of management.
Zone by Zone Coverage
Typical starting scope for a single floor, confirmed on survey. A floor of six to twelve cameras is normal for reception, corridor, server room, back exit and open floor coverage.
| Zone | What the camera is for | Notes |
|---|---|---|
| Reception and main entrance | Face capture of everyone entering and leaving | Mount facing the door at head height, not overhead. Overhead gives you scalps. |
| Corridors and floor landings | Movement between departments and after-hours presence | One camera per corridor run is usually enough if it looks along the length. |
| Open work floor | General activity and equipment security | Wide overview only. Cameras aimed at an individual desk or screen invite grievances. |
| Server and IT room | Who entered and what they carried | Pairs well with a door access reader so entry is logged as well as recorded. |
| Accounts and cash handling | Cash movement and document handover | A dedicated angle across the desk, not a ceiling dome above it. |
| Store and stationery room | Stock movement and consumables | Common source of low-level, long-running loss in workplaces. |
| Back and fire exits | The doors that are not watched by anyone | Cover them, but never obstruct or lock a fire exit for camera convenience. |
| Parking and approach | Vehicles, deliveries and damage claims | Plate capture needs a dedicated angle at a controlled entry, not a corner camera. |
Attendance and Door Access Alongside the Cameras
Most workplace enquiries we receive combine cameras with attendance and door control, and it is cheaper to cable both at the same time.
Fingerprint attendance
Straightforward and familiar for staff, though shared-surface hygiene and worn fingerprints on manual workers are worth considering before you commit.
Face recognition devices
Contactless and faster at shift change, which matters when a hundred people arrive in the same ten minutes.
Card and RFID readers
Useful for contractors and visitors who should have time-limited access without being enrolled biometrically.
Electric locks and exit buttons
Magnetic or drop-bolt locks with an exit button inside and a documented release arrangement for emergencies.
Server room control
A single controlled door with logged entry, paired with a camera facing the rack, is the highest-value access point in most workplaces.
Reports for HR
Attendance data exported for payroll, with the recorder retained as the reference when a punch is disputed.
Cabling, Racks and Doing It Once
Camera cabling in a workplace should be part of the structured cabling, not an afterthought stapled along a skirting board. That means Cat6 to each point, a patch panel in the rack, labelled ports at both ends and data kept away from parallel power runs. Six months later, when a camera goes offline, a labelled port turns a two-hour hunt into a two-minute check.
Where a run to a far corner or an adjoining block exceeds 100 metres, the fix is a second switch at an intermediate point or a fibre link, not a longer copper cable. We size the PoE switch to the real camera load with headroom, because a switch running at its power ceiling drops cameras at exactly the wrong moment.
The recorder belongs in a ventilated, lockable position — a rack in the IT room, not on top of a cupboard in the corridor. Anyone who can reach the recorder can wipe it, which defeats the entire system.
Staff Privacy and Sensible Limits
Workplace cameras work better when staff understand them. These are the boundaries we recommend to every client.
- No cameras in washrooms or prayer areas — There is no scenario in which this is acceptable, and we will not install them.
- Audio normally disabled — Recording staff and visitor conversations is a different matter to recording movement. We leave audio off unless there is a clear, agreed reason.
- Overview, not surveillance of individuals — Cameras cover areas and entry points. A camera fixed on one employee’s desk or screen creates grievances and rarely solves anything.
- Tell staff in writing — A short written notice and signage at the entrance removes most objections before they start.
- Restrict who can view — Separate accounts with per-channel permissions so a floor supervisor sees their floor and not the accounts room.
- Log the exports — Keep a simple record of who exported which clip and why, so footage handling is traceable.
Power, Generators and Staying Recorded
Lahore workplaces almost always have a generator or a UPS already, and the system still fails if the recorder is on the wrong circuit. The recorder, the PoE switch and the internet router all need to be on the protected supply, otherwise you lose both recording and remote access for the changeover window.
Generator changeover also puts electrical noise and surge onto the supply. A rack-level UPS with surge protection is worth more here than in a home, and long external runs to gate or parking cameras should have surge protection and proper earthing at the outdoor end.
Managers and owners usually want to see the workplace when they are not in it. That is a one-line setting once the network is right, and we cover the detail — including the CGNAT problem on Pakistani broadband — on our remote monitoring page.
From Enquiry to Handover
Survey with the facilities or IT contact
We walk the floor with whoever owns the building side, agree camera positions and check the rack, DB and internet arrangement.
Written scope and itemised quotation
Camera schedule, recorder and storage sizing, switch, cabling metres, access hardware and labour, each line clear enough for approval.
Scheduled installation
Cabling planned around working hours or over a weekend where the floor cannot be disrupted.
Configuration
Recording schedule, retention days, user accounts and permissions, attendance enrolment and door timing.
Handover and documentation
Camera layout drawing, port labelling record, account list and a walkthrough for the person who will actually operate it.
Documentation, Invoicing and Ongoing Support
Company purchases need paperwork. Every job comes with a written scope, an itemised quotation and an invoice for your records.
For ongoing cover, we can arrange a scheduled maintenance visit for lens cleaning, storage checks and firmware review, which matters more in Lahore than most places because dust and smog season visibly degrades dome bubbles and lens clarity within a year.
Get a Written Quotation for Your Workplace
Message us on WhatsApp with your floor size and camera count, or email info@strixlink.com for a scope document. Hardware is quoted as Contact for Price against your actual requirement.
Frequently asked questions
How many cameras does a single office floor need?
Six to twelve is the usual range for one floor covering reception, corridor, open work area, server room, store and back exit. Cash handling, multiple entrances or a parking area push it higher.
Can we install cameras and biometric attendance in the same job?
Yes, and it is the sensible way to do it because both use the same cable routes and the same rack. Doing them separately means opening the same ceiling twice.
Are we allowed to put cameras where staff work?
Covering shared areas, entrances and cash points is normal practice. We advise informing staff in writing, putting signage at the entrance and avoiding cameras aimed at individual desks or screens, which is where most disputes come from.
Can each manager see only their own area?
Yes. Recorders support multiple user accounts with per-channel permissions, so a branch or floor manager sees their own cameras while the full system stays with the owner or the IT administrator.
Will you provide an invoice for company records?
Yes, every job is quoted and invoiced in writing with itemised lines.
Do you take on maintenance for a system another company installed?
Yes. We service Pollo systems whoever installed them, and we will tell you honestly if the existing cabling or recorder is the real problem rather than selling around it.
How long should a workplace keep recordings?
It depends on how quickly issues surface in your business. Where disputes come to light at month end, a retention window that comfortably covers a full month is a sensible target, and we size the storage for the days you specify.
