5 Megapixel Thermal Vision Network Dome Camera

Pollo Security Model: PLC-435M-THC-IR3PM Available in Lahore

Contact for Price

Resolution: 5 MP
Night-View Distance: 30 m
Housing Type: Dome
Thermal:
Optical:
Line Crossing Detection

Quantity

Get a Quote on WhatsApp Request Installation on WhatsApp

Need availability or technical advice? Ask on WhatsApp

Stock changes daily. Please confirm availability on WhatsApp before travelling.

WarrantyAll Pollo Security products supplied by StrixLink carry the manufacturer warranty. Confirm the exact warranty term for your model on WhatsApp before you order.
InstallationProfessional installation available across Lahore. Installation is quoted separately based on the number of cameras, cable runs and site conditions.
DeliveryDelivery available across Lahore and to other cities in Pakistan. Delivery time and charges are confirmed when you place your order.

About the 5 Megapixel Thermal Vision Network Dome Camera

The dome version of Pollo's thermal and optical pairing places a 256 × 192 thermal sensor and a 2880 × 1620 optical camera behind one cover, which is often the preferred shape under a soffit, a canopy or a factory ceiling. Thermal readings run from −20 °C to 150 °C and can be displayed live on the stream, with alarms for temperature exceptions and fire backed by sound and light warning. The optical channel provides a 30 m infrared rating and full-colour night vision. Choose the dome where the camera should sit tight to a ceiling line, and the bullet where a clearly aimed camera is part of the deterrent.

Key benefits

Thermal and visible images can be combined for a clearer picture of an incident
12 μm thermal pixels with NETD ≤ 50 mK produce a stable, readable heat image
Live on-screen temperature data lets an operator watch a hot spot rather than guess
Fire detection and temperature-exception alarms trigger sound and light warning at the camera itself
Optical channel at 2880 × 1620 with 0.02 lux minimum illumination covers ordinary daytime duty
IP67 rating with DC12V or PoE (IEEE802.3af) power fits standard ceiling and soffit cable runs

Where it works well

Ceiling of a warehouse aisle storing flammable stock
Soffit above a generator or electrical panel room door
Under a canopy at a paint or chemical store
Server or UPS room where heat is the main risk
Covered loading dock in a Lahore industrial unit

Technical specifications

Manufacturer-published specifications. Confirm critical figures against the datasheet before ordering.

Resolution	5 MP
Pixel Resolution	2880 × 1620
Image Sensor	1/2.7" CMOS
Night-View Technology	Thermal Imaging, Full-Colour Night Vision, Infrared (IR)
Night-View Distance	30 m
Housing Type	Dome
Weather Rating	IP67
Connectivity	PoE
Power Supply	DC12V

Features

Thermal:
256 × 192 thermal sensor resolution for clear and detailed heat images.
12 μm pixel size with NETD ≤ 50 mK (@25 °C, F1.0), ensuring accurate detection.
Measures temperatures from -20 °C to 150 °C, suitable for various industrial and security applications.
Supports White Hot, Black Hot, Iron Oxide Red, Rainbow, and more for flexible visualization.
Built-in sound and light warnings with temperature-exception alarms and fire detection
Motion Detection Alarm Trigger
Line Crossing Detection
Region Intrusion Detection
Human and motor-vehicle classification for reduced false alarms
Combines thermal and visible images for enhanced situational awareness.
Displays real-time temperature data directly on the video stream
Optical:
1/2.7 " CMOS Image Sensor
2880×1620 Pixels (3K) Resolution
0.02 Lux Min. Illumination for Day Time Color View
30-meter IR Night View Range @ 0 Lux
Highlight Compensation for Image Correction
Backlight Compensation for Image Correction
ONVIF Protocol Supported
IP67 Water & Dust Proofing
DC12V/ PoE (IEEE802.3af) Power Supply

Frequently asked questions

Dome or bullet — which should I take?

The electronics are the same on both: a 256 × 192 thermal sensor, a 2880 × 1620 optical channel, a 30 m infrared rating and the same alarm functions. The choice is mounting and appearance. A dome sits flush under a ceiling or soffit and is less obtrusive; a bullet is easier to aim precisely along a wall and is more visible, which some sites want.

What does NETD ≤ 50 mK mean, and should I care?

NETD describes the smallest temperature difference the sensor can distinguish, so a lower figure means a cleaner image with less noise between objects at similar temperatures. At ≤ 50 mK this sensor separates a warm motor from its surroundings without the picture washing out. For general security detection it is more than adequate; for precision laboratory measurement it is not that class of instrument.

How do the two images appear together?

The camera supports combining thermal and visible views, and can overlay real-time temperature data on the stream. Exactly how that is presented, recorded and played back depends on the recorder or VMS you use with it. Tell us what platform you are running on WhatsApp and we will confirm before installation.

How do I get a quotation?

Message +92 300 0030132 with the area to be covered, the ceiling height and what should happen when an alarm triggers. Prices are confirmed there rather than listed, and we will include the cabling and any alarm wiring in the figure.
