Authorised Pollo Security dealer in Lahore — CCTV supply, installation and support. Authorised Pollo dealer in Lahore Get a quote

All-in-One Management Server with 2-SATA (PLC-MSA510-MTSC-E) — Pollo Security, available from StrixLink Lahore

All-in-One Management Server with 2-SATA

Pollo Security Model: PLC-MSA510-MTSC-E Available in Lahore

Contact for Price

  • Screen Size: 19"
  • Advanced Video Decoding up to 8MP cameras
  • Linux Operating System – secure & highly stable
  • Dual Gigabit Network Cards (4× LAN ports total)
  • High Decoding Power – up to 128 channels output
  • Industrial-Grade Reliability for 24/7 operation

Stock changes daily. Please confirm availability on WhatsApp before travelling.

Download datasheet (PDF) 514 KB
  • WarrantyAll Pollo Security products supplied by StrixLink carry the manufacturer warranty. Confirm the exact warranty term for your model on WhatsApp before you order.
  • InstallationProfessional installation available across Lahore. Installation is quoted separately based on the number of cameras, cable runs and site conditions.
  • DeliveryDelivery available across Lahore and to other cities in Pakistan. Delivery time and charges are confirmed when you place your order.

About the All-in-One Management Server with 2-SATA

Think of this as the brain of a large camera network rather than another recorder. It runs Linux on an Intel E-2200 series processor with 8GB of ECC memory, manages up to 2048 channels out of the box and up to 500 devices, and moves 640 Mbps of video in and out. The catch worth understanding: with only two 3.5-inch bays plus a 128GB SSD, it is built to manage and decode video, not to store months of it, so bulk recording belongs on SAN or streaming media storage behind it. Availability and pricing in Lahore are confirmed on WhatsApp.

Key benefits

  • Manages up to 2048 channels and 500 devices, with further expansion available under authorisation.
  • ECC memory and a Linux base suit a machine expected to run continuously.
  • Decodes up to 128 channels of output, including 8MP cameras, for wall display.
  • Four LAN ports across dual gigabit cards separate camera traffic from client traffic.
  • A vehicle database of 10,000 plates, plus 256 user accounts with 64 online together.
  • Standard 19-inch rack build with VGA, HDMI, DP, USB 3.1 and audio interfaces.

Where it works well

  • Control room for a large housing society in Lahore
  • Central monitoring for a multi-block textile mill on Multan Road
  • Campus-wide camera management for a private university
  • Gate and vehicle monitoring across an industrial estate
  • Head-office viewing wall consolidating several branch sites

Technical specifications

Manufacturer-published specifications. Confirm critical figures against the datasheet before ordering.

Screen Size19"
Panel Resolution8 MP
Bandwidth640 Mbps incoming bandwidth

Features

  • Intel® Core™ E-2200 Processor for enterprise-grade performance
  • Linux Operating System – secure & highly stable
  • 8GB DDR4 ECC Memory for error-free continuous operation
  • Dual Gigabit Network Cards (4× LAN ports total)
  • Built-in Storage: 128GB SSD + 2× 3.5” HDD slots (up to 8TB each)
  • Massive Channel Capacity – up to 2048 channels (expandable to 20,000)
  • Supports 500 Devices (expandable with authorization)
  • High Decoding Power – up to 128 channels output
  • Advanced Video Decoding up to 8MP cameras
  • 640 Mbps Incoming & Outgoing Bandwidth for large networks
  • Up to 36CH Local Real-Time Preview with auto view switching
  • PTZ Control Support with permissions, presets & locking
  • Vehicle Database – supports 10,000 license plates
  • Multi-User Access – up to 256 users, 64 online simultaneously
  • Flexible Recording Modes – scheduled, manual & alarm-based
  • Supports SAN / Streaming Media Storage Architecture
  • Rich Interfaces – VGA, HDMI, DP, USB 3.1, Audio I/O
  • Standard 19-inch Rack-Mount Design for control rooms
  • Industrial-Grade Reliability for 24/7 operation

Frequently asked questions

Does this replace the NVRs we already have?

No. It sits above them, handling device management, decoding, user permissions and PTZ control with presets and locking. Recording generally stays on the NVRs or on SAN and streaming media storage, which this platform is designed to work with.

How much storage does it hold internally?

There is a 128GB SSD for the system plus two 3.5-inch bays taking up to 8TB each. That is deliberately modest, because the unit is a management and decoding server rather than a bulk recorder. For long retention across a large site, plan external storage in the architecture from the start.

Can it drive a video wall?

It supports decoding up to 128 channels of output and up to 36 channels of local real-time preview with automatic view switching, through VGA, HDMI and DP. Whether that matches your intended wall layout depends on the panels and any splicing controller involved. Send us the wall design on WhatsApp and we will confirm the combination.

What do we need to install alongside it?

It is a 19-inch rack-mount unit built for continuous operation, so it wants a proper cabinet with ventilation and clean, backed-up power. Network capacity also has to match the 640 Mbps figure rather than being assumed. We usually walk through the switching and power design before quoting.

Need this installed in Lahore?

Send the model number on WhatsApp for the current price, availability and a full installation quote.

Specifications sourced from the Pollo Security product page: https://www.pollosecurity.com/products/plc-msa510-mtsc-e-all-in-one-management-server-2-sata
